                ESM 530-550S

      3.












                                        ESM 530-550S










                                        ESM 530-550S








                                        ESM 530-550S








                                        ESM 530-550S


















                                                        ESM 530-550S



                            南京沃利特新能源科技有限公司











                價 格：







                        起價 ￥1.58 / Wp *















                    類型：


                    背鈍化





                    功率范圍：


                    530 ~ 550 Wp






                    地區：


                    中國大陸
                    中國大陸






















                                                                                                                            注意： 您的詢盤將直接發送至南京沃利特新能源科技有限公司。













                        描述：



    1. High efficiency PERC cell, half-cut technology;
    2. Positive power tolearance up to +5W;
    3. 30 years' warranty for minimum 83% power output;
    4. TUV, CE, INMETRO, ISO, PV Cycle certified;
    5. 5400Pa mechanical strength;
    6. Available in both white and black colors.




















    產品特點








                產品型號












                                                                                                                                                                                                                         ESM-530S


                                                                                                                                                                                                                         ESM-535S


                                                                                                                                                                                                                         ESM-540S


                                                                                                                                                                                                                         ESM-545S


                                                                                                                                                                                                                         ESM-550S

















            質量保證











                    產品質量保證




                                                                        12 年








                    功率輸出保證




                                            12年期92%輸出功率保證，30年期83%輸出功率保證








            電性能參數（STC）










                峰值功率 （Pmax）












                                                                                                                                                                                                                         530 Wp


                                                                                                                                                                                                                         535 Wp


                                                                                                                                                                                                                         540 Wp


                                                                                                                                                                                                                         545 Wp


                                                                                                                                                                                                                         550 Wp















                峰值工作電壓（Vmpp）












                                                                                                                                                                                                                         41.4 V


                                                                                                                                                                                                                         41.55 V


                                                                                                                                                                                                                         41.7 V


                                                                                                                                                                                                                         41.85 V


                                                                                                                                                                                                                         42 V















                峰值工作電流（Impp）












                                                                                                                                                                                                                         12.81 A


                                                                                                                                                                                                                         12.88 A


                                                                                                                                                                                                                         12.95 A


                                                                                                                                                                                                                         13.03 A


                                                                                                                                                                                                                         13.1 A















                開路電壓（Voc）












                                                                                                                                                                                                                         49.25 V


                                                                                                                                                                                                                         49.4 V


                                                                                                                                                                                                                         49.55 V


                                                                                                                                                                                                                         49.7 V


                                                                                                                                                                                                                         49.85 V















                短路電流（Isc）












                                                                                                                                                                                                                         13.73 A


                                                                                                                                                                                                                         13.79 A


                                                                                                                                                                                                                         13.85 A


                                                                                                                                                                                                                         13.91 A


                                                                                                                                                                                                                         13.97 A















                組件效率












                                                                                                                                                                                                                         20.5 %


                                                                                                                                                                                                                         20.7 %


                                                                                                                                                                                                                         20.9 %


                                                                                                                                                                                                                         21.1 %


                                                                                                                                                                                                                         21.3 %




















            標準測試條件（STC）：太陽能輻射通量1000W/m2，大氣參數1.5，組件溫度25℃。








            電性能參數（NOCT）











                峰值功率 （Pmax）












                                                                                                                                                                                                                         394 Wp


                                                                                                                                                                                                                         398 Wp


                                                                                                                                                                                                                         402 Wp


                                                                                                                                                                                                                         405 Wp


                                                                                                                                                                                                                         409 Wp















                峰值工作電壓（Vmpp）












                                                                                                                                                                                                                         37.84 V


                                                                                                                                                                                                                         37.91 V


                                                                                                                                                                                                                         38.08 V


                                                                                                                                                                                                                         38.25 V


                                                                                                                                                                                                                         38.42 V















                峰值工作電流（Impp）












                                                                                                                                                                                                                         10.42 A


                                                                                                                                                                                                                         10.5 A


                                                                                                                                                                                                                         10.55 A


                                                                                                                                                                                                                         10.6 A


                                                                                                                                                                                                                         10.65 A















                開路電壓（Voc）












                                                                                                                                                                                                                         46.5 V


                                                                                                                                                                                                                         46.57 V


                                                                                                                                                                                                                         46.65 V


                                                                                                                                                                                                                         46.74 V


                                                                                                                                                                                                                         46.84 V















                短路電流（Isc）












                                                                                                                                                                                                                         11.07 A


                                                                                                                                                                                                                         11.14 A


                                                                                                                                                                                                                         11.19 A


                                                                                                                                                                                                                         11.27 A


                                                                                                                                                                                                                         11.33 A
















                    最大耐久溫度




                                                                        45±2 °C











            電池片標稱工作溫度（NOCT）：太陽能輻射通量800W/m2，大氣參數1.5，環境溫度20℃，風速1 m/s。








            溫度特性












                    工作溫度




                                                                        -40~85 °C








                    溫度系數（Pmax）




                                                                        -0.36 %/°C








                    溫度系數（Voc）




                                                                        -0.26 %/°C








                    溫度系數（Isc）




                                                                        0.04 %/°C








            系統集成參數












                    最大系統電壓




                                                                        1500 V








                    保險絲額定電流




                                                                        25 A








            物理參數












                    組件尺寸（高/寬/厚）




                                                                        2279x1134x35 mm








                    重量




                                                                        28.5 kg








                    電池片類型




                                            背鈍化










                    電池片數量




                                                                        144








                    玻璃類型




                                            鋼化








                    玻璃厚度




                                                                        3.2 mm












                    邊框類型




                                            陽極氧化鋁合金








                    旁路二極管數




                                                                        3








                    接線盒防護等級




                                                                        IP 68








                    連接器類型




                                                                        MC4








                    電纜截面




                                                                        4 mm2








                    電纜長度




                                                                        1100 mm









            PDF











                    下載公司產品詳情


















































		Project Picture




































                                    南京沃利特新能源科技有限公司













                                                                                                    +86 13813088384







                                                    www.einnova-solarline.com







                                                中國大陸






    Building 1,NO.58, Yunjin Road, Jianye District, Nanjing, China





                                                員工數：

                                                    1,000





                                                母公司：

                                                    EINNOVA SOLARLINE GROUP














                                        注意： 您的詢盤將直接發送至南京沃利特新能源科技有限公司。
















    晶體硅





                                        產量 (MW)/：

                                             MWp









                                        單晶硅，多晶硅




                                        功 率 范 圍(Wp)：

                                            5-700












                                    有用聯系人




                                                                                    Contact Face



                                                Emma Wu







                                                                                    Contact Face



                                                Vicky Chen













                公司描述

















    Einnova Solarline Energy Corp. Limited was founded in 2008, specializing in the manufacturing and R&D of premium solar modules for clients all over the world. In past 15 years, Einnova Solarline has been developing rapidly and making great achievements, growing into one of the leading solar module manufacturers in the world. Einnova Solarline has been ranked as Top 20 Solar Module Manufacturers in China for past three years.
    Thanks to its superior expertise in manufacturing, experienced and talented technical team, rich R&D experience, strong financial strength and management system, good relationship with strategical partners, Einnova Solarline has been able to manufacture and supply the most reliable solar modules in the world with good quality and competitive costs.
    So far, Einnova Solarline has supplied solar modules to more than 50 countries globally, including Europe, North America, Asia, Africa, Middle East, South America etc. with accumulated installation capacity of more than 8G watts.
    QUALITY lies in the hearts of Einnova team as it is the foundation for our long term development. We always use first-class raw materials to guarantee good quality. Besides this, we have state-of-the-art and customized full-automatic production lines which help us to maintain reliable and durable product quality. And we use uniquely designed cloud-manufacturing IT system for full tracking records of each solar module – that’s one of our biggest advantages over other competitors for quality control.
    Our goal is to guarantee “each piece of solar module from Einnova Solarline production line fully comply with IEC 61215 and 61730 quality standards”. We have successfully got TUV, CE, INMETRO, PV CYCLE etc. certificates and our manufacturing systems fully comply with ISO 9000, ISO 14000 and OHSAS 18000 criterias.
    Our production capacity stands at 1.6GW for the moment and we have four factories in mainland China and Taiwan. The fifth factory in Vietnam is in construction, which willl help to further expand our production capacity in near future and enhance our capability to serve more clients in the world.
    Einnova Solarline looks forward to cooperation with you to build a better, greener and brighter future together!
